DBX RTA-M

he optional RTA-M real time audio analyzing mic is the perfect accessory tool for the DriveRack PA series (PA, PX, PA+, PA2) and 260. Used in conjunction with the System Setup Wizard and Auto EQ Wizard the RTA-M is ideal for optimizing the sound quality of even the most difficult of acoustic environments.

Polar Pattern : omni-directional

Element : back electret-Condenser

Frequency Response : 20 Hz – 20 kHz

Impedance : 250 30% (at 1,000Hz)

Sensitivity : -63 dB +-3 dB ( 0 dB=1V/ microbar 1,000 Hz indicated by open circuit )

Operating Voltage : phantom power 9V-52VDC

Element Back Electret Condenser

Polar Pattern Omnidirectional

Frequency Range 20 Hz ~ 20,000Hz

Impedance 250 Ω ± 30% (@ 1KHz)

Operating Voltage 9~52V DC Phantom Power

Sensitivity -63 dB ± 3 dB (0 dB=1V/microbar 1,000 Hz indicated by open circuit)

Dimensions Ø10(mic head) x 145(L) mm
